Good recovery rate Mineral Separator flotation machine

.jpg

The Flotation Mineral separator machine is the latest design to use the circular tank concept and combines the   benefits of circular cells with the unique features of the Minerals mechanism to create the ideal conditions to maximize floatation performance for all roughing, cleaning and scavenging duties. The machine can be used to separate nonferrous metal,ferrous metal,noble metal, nonmetallic mine,chemical material and recycle mine.



Detailed Product Description

Flotation Mineral separator machine is widely used for roughing, concentrating and recovering flotation of nonferrous metals that include copper, lead, zinc, nickel and molybdenum, ferrous metal, It can also be used for separating nonmetallic minerals, like coal and fluorite.

XJK series of flotation mineral separator machine can effectively make the low-grade ores become high-grade concentrates, especially for disseminated, complex ores,dealing with them can get better separation efficiency.



Flotation mineral separator Features:

1. large air-absorption capacity
2. low energy consumption
3. less reagents consumption
4. easy to maintenance and can be designed according to the users.
5. Every cell owns three functions: air absorption, slurry absorption, and flotation separation,and the cells form a flotation separation loop by itself without any auxiliary equipment, and is allocated horizontally,which favors the change of flow.
6. The impeller has backward-inclined upper and lower vanes, which produce upper and lower circulation of mineral slurry respectively.



SF series Flotation mineral separator Technical Specifications:

Model of gold flotation machine

SF-0.37

SF-0.7

SF-1.2

SF-2.8

SF-4

Tank Volume
(m3)

0.37

0.7

1.2

2.8

4

Impeller Dia.
(mm)

300

350

450

550

650

Capacity
(m3/min)

0.2-0.4

0.3-0.9

0.6-1.2

1.5-3.5

2-4

Impeller Rotate Speed
(m3/min)

352

400

312

268

238

Motor

Model

 Y90L-4

Y100L2-4

Y132M2-6

Y160L-6

Y180L-6

 Y90S-4

Y90S-4

Y90S-4

Y90S-4

Y90L-4

Power
(Kw)

1.5

3

5.5

11

15

1.1

1.1

1.1

1.1

1.5

Overall Dimension
(mm)

700×700×750

900×820×950

1100×1100×1100

1700×1600×1150

1850×2050×1200

Unit Weight (kg)

468

600

1373

2338

 2660

XJK series Flotation mineral separator machines Technical Specifications:

Model of gold flotation machine

XJK-0.35(3A)

XJK-0.62(4A)

XJK-1.1(5A)

XJK-2.8(6A)

XJK-5.8(7A)

Effective Volume(m3)

0.35

0.62

1.1

2.8

5.8

Capacity(m3/min)

0.18~0.4

0.3~0.9

0.6~1.6

1.5~3.5

3~7

Rotate Speed(r/min)

470

400

330

280

240

Impeller Dia (mm)

300

350

500

600

750

Motor

Model

Rotator

Y90L-4

Y100L2-4

Y132M2-6

Y160L-6

Y200L2-6(Y225M-6)

Scraper

Y90S-4

Y90S-4

Y90S-4

Y90S-4

Y90L-4

Power(Kw)

Impeller Motor

1.5

3

5.5

11

22(30)

Scraper Motor

1.1

1.1

1.1

1.1

1.5

Weight(t/Single Tank)

0.43

0.86

1.38

2.33

3.533




Structure and working principle

XJK series of Flotation mineral separator machine consists of flotation cells,impeller,belt pulley,inlet pipe, strobe,covering plate,standpipe,draw bar,etc.

When the floatation mineral separator machine works, the motor drives the impeller to revolve, so the centrifugal effect and negative pressure are produced. On one hand, ample air is absorbed and mixed with mineral slurry, on the other hand, the mixed mineral slurry is mingled with additive, meanwhile, the foams are thinning, the mineral is bounded with foams, and floats up to the surface of mineral slurry and the mineralized foam is formed.The liquid surface can be adjusted with the height of adjustment flash board, so that the useful foams are scraped with squeegee.



 High quality XJK series Flotation mineral separator machine in our workshop

paste-pic-dp_uuid_mlz8z


Pictures of SF series Flotation Mineral Separator machine from our workshop shown below:

Flotation Mineral Separator machine from mine site

Lead zinc Mineral separator.jpg

Tungsten ore purification equipment.jpgNEW_Flotation_Machine_for_various_ore_from.jpg

Welcome to visit our factory in your free time!

Also you could send to my email as follow:

1.Name of raw ore?

2.Production capacity (t/h)?

3.Particle size of raw ore(mm)?



We will suggest you the best type machine.
